ELECTRO PJP - Testing patchcords MFS/MFS 1000V CAT II

Click to zoom

For illustration purpose only

Brand :	ELECTRO PJP

Stackable. Reinforced insulation. Max voltage: 1000V.

600 V CAT III
1000 V CAT II

Stackable. Reinforced insulation. Max voltage: 1000V.

600 V CAT III
1000 V CAT II

Code number	Supplier	Material	Temperature	Section (mm²)	Max. current (A)	Length (mm)	Length (m)	Color	Stock	Price ( ExVAT )
389 73010	2611-IEC-10N 109768	Silicone	-60 / +180	0,75	12	100		Black	Login required
389 73012	2611-IEC-10R 109769	Silicone	-60 / +180	0,75	12	100		Red	Login required
389 73014	2611-IEC-10J 109767	Silicone	-60 / +180	0,75	12	100		Yellow	Login required
389 73015	2611-IEC-10V 109770	Silicone	-60 / +180	0,75	12	100		Green	Login required
389 73016	2611-IEC-10BL 109766	Silicone	-60 / +180	0,75	12	100		Blue	Login required
389 73019	2611-IEC-10BC 109765	Silicone	-60 / +180	0,75	12	100		White	Login required
389 7301Y	2611-IEC-10JV 123838	Silicone	-60 / +180	0,75	12	100		Yellow/Green	Login required
389 73020	2611-IEC-25N 109783	Silicone	-60 / +180	0,75	12	250		Black	Login required
389 73041	2611-IEC-25BN 225134	Silicone	-60 / +180	0,75	12	250		Brown	Login required
389 73022	2611-IEC-25R 109784	Silicone	-60 / +180	0,75	12	250		Red	Login required
389 73044	2611-IEC-25J 109782	Silicone	-60 / +180	0,75	12	250		Yellow	Login required
389 73045	2611-IEC-25V 109785	Silicone	-60 / +180	0,75	12	250		Green	Login required
389 73026	2611-IEC-25BL 109781	Silicone	-60 / +180	0,75	12	250		Blue	Login required
389 73029	2611-IEC-25BC 109780	Silicone	-60 / +180	0,75	12	250		White	Login required
389 7304Y	2611-IEC-25JV 123839	Silicone	-60 / +180	0,75	12	250		Yellow/Green	Login required
Code number	Supplier	Material	Temperature	Section (mm²)	Max. current (A)	Length (mm)	Length (m)	Color	Stock	Price ( ExVAT )
389 73050	2611-IEC-50N 109789	Silicone	-60 / +180	0,75	12	500		Black	Login required
389 73052	2611-IEC-50R 109790	Silicone	-60 / +180	0,75	12	500		Red	Login required
389 73054	2611-IEC-50J 109788	Silicone	-60 / +180	0,75	12	500		Yellow	Login required
389 73055	2611-IEC-50V 109791	Silicone	-60 / +180	0,75	12	500		Green	Login required
389 73056	2611-IEC-50BL 109787	Silicone	-60 / +180	0,75	12	500		Blue	Login required
389 73059	2611-IEC-50BC 109786	Silicone	-60 / +180	0,75	12	500		White	Login required
389 7305Y	2611-IEC-50JV 123840	Silicone	-60 / +180	0,75	12	500		Yellow/Green	Login required
389 73100	2611-IEC-100N 109772	Silicone	-60 / +180	0,75	12		1	Black	Login required
389 73101	2611-IEC-100BN 225132	Silicone	-60 / +180	0,75	12		1	Brown	Login required
389 73102	2611-IEC-100R 123808	Silicone	-60 / +180	0,75	12		1	Red	Login required
389 73104	2611-IEC-100J 123807	Silicone	-60 / +180	0,75	12		1	Yellow	Login required
389 73105	2611-IEC-100V 109773	Silicone	-60 / +180	0,75	12		1	Green	Login required
389 73106	2611-IEC-100BL 109771	Silicone	-60 / +180	0,75	12		1	Blue	Login required
389 73109	2611-IEC-100BC 123806	Silicone	-60 / +180	0,75	12		1	White	Login required
389 7310Y	2611-IEC-100JV 109814	Silicone	-60 / +180	0,75	12		1	Yellow/Green	Login required
Code number	Supplier	Material	Temperature	Section (mm²)	Max. current (A)	Length (mm)	Length (m)	Color	Stock	Price ( ExVAT )
389 73151	2611-IEC-150BN 225133	Silicone	-60 / +180	0,75	12		1,5	Brown	Login required
389 73154	2611-IEC-150J 123810	Silicone	-60 / +180	0,75	12		1,5	Yellow	Login required
389 73155	2611-IEC-150V 109776	Silicone	-60 / +180	0,75	12		1,5	Green	Login required
389 73156	2611-IEC-150BL 109774	Silicone	-60 / +180	0,75	12		1,5	Blue	Login required
389 73159	2611-IEC-150BC 123809	Silicone	-60 / +180	0,75	12		1,5	White	Login required
389 73200	2611-IEC-200N 109778	Silicone	-60 / +180	0,75	12		2	Black	Login required
389 73201	2611-IEC-200BN 123813	Silicone	-60 / +180	0,75	12		2	Brown	Login required
389 73202	2611-IEC-200R 123815	Silicone	-60 / +180	0,75	12		2	Red	Login required
389 73204	2611-IEC-200J 123814	Silicone	-60 / +180	0,75	12		2	Yellow	Login required
389 73205	2611-IEC-200V 109779	Silicone	-60 / +180	0,75	12		2	Green	Login required
389 73206	2611-IEC-200BL 109777	Silicone	-60 / +180	0,75	12		2	Blue	Login required
389 73209	2611-IEC-200BC 123812	Silicone	-60 / +180	0,75	12		2	White	Login required
389 7320Y	2611-IEC-200JV 123837	Silicone	-60 / +180	0,75	12		2	Yellow/Green	Login required
389 31040	2619-IEC-25N 109833	Silicone	-60 / +180	1	20	250		Black	Login required
389 31042	2619-IEC-25R 224488	Silicone	-60 / +180	1	20	250		Red	Login required
Code number	Supplier	Material	Temperature	Section (mm²)	Max. current (A)	Length (mm)	Length (m)	Color	Stock	Price ( ExVAT )
389 31046	2619-IEC-25BL 224487	Silicone	-60 / +180	1	20	250		Blue	Login required
389 31049	2619-IEC-25BC 109831	Silicone	-60 / +180	1	20	250		White	Login required
389 3104Y	2619-IEC-25JV 109832	Silicone	-60 / +180	1	20	250		Yellow/Green	Login required
389 31050	2619-IEC-50N 109816	Silicone	-60 / +180	1	20	500		Black	Login required
389 31052	2619-IEC-50R 109837	Silicone	-60 / +180	1	20	500		Red	Login required
389 31054	2619-IEC-50J 109835	Silicone	-60 / +180	1	20	500		Yellow	Login required
389 31055	2619-IEC-50V 224489	Silicone	-60 / +180	1	20	500		Green	Login required
389 31056	2619-IEC-50BL 109834	Silicone	-60 / +180	1	20	500		Blue	Login required
389 31058	2619-IEC-50G 109838	Silicone	-60 / +180	1	20	500		Grey	Login required
389 3105Y	2619-IEC-50JV 109836	Silicone	-60 / +180	1	20	500		Yellow/Green	Login required
389 31100	2619-IEC-100N 109828	Silicone	-60 / +180	1	20		1	Black	Login required
389 31102	2619-IEC-100R 109829	Silicone	-60 / +180	1	20		1	Red	Login required
389 31104	2619-IEC-100J 109826	Silicone	-60 / +180	1	20		1	Yellow	Login required
389 31105	2619-IEC-100V 224486	Silicone	-60 / +180	1	20		1	Green	Login required
389 31106	2619-IEC-100BL 109825	Silicone	-60 / +180	1	20		1	Blue	Login required
Code number	Supplier	Material	Temperature	Section (mm²)	Max. current (A)	Length (mm)	Length (m)	Color	Stock	Price ( ExVAT )
389 3110Y	2619-IEC-100JV 109827	Silicone	-60 / +180	1	20		1	Yellow/Green	Login required
389 31150	2619-IEC-150N 225170	Silicone	-60 / +180	1	20		1,5	Black	Login required
389 31152	2619-IEC-150R 225171	Silicone	-60 / +180	1	20		1,5	Red	Login required
389 31155	2619-IEC-150V 225172	Silicone	-60 / +180	1	20		1,5	Green	Login required
389 31156	2619-IEC-150BL 225169	Silicone	-60 / +180	1	20		1,5	Blue	Login required
389 31159	2619-IEC-150BC 123884	Silicone	-60 / +180	1	20		1,5	White	Login required
389 31200	2619-IEC-200N 109819	Silicone	-60 / +180	1	20		2	Black	Login required
389 31202	2619-IEC-200R 109820	Silicone	-60 / +180	1	20		2	Red	Login required
389 31204	2619-IEC-200J 224478	Silicone	-60 / +180	1	20		2	Yellow	Login required
389 31205	2619-IEC-200V 224479	Silicone	-60 / +180	1	20		2	Green	Login required
389 31206	2619-IEC-200BL 109817	Silicone	-60 / +180	1	20		2	Blue	Login required
389 31209	2619-IEC-200BC 224477	Silicone	-60 / +180	1	20		2	White	Login required
389 3120Y	2619-IEC-200JV 109818	Silicone	-60 / +180	1	20		2	Yellow/Green	Login required
389 51040	2613-IEC-25N 109720	Silicone	-60 / +180	1,5	25	250		Black	Login required
389 51045	2613-IEC-25V 109722	Silicone	-60 / +180	1,5	25	250		Green	Login required
Code number	Supplier	Material	Temperature	Section (mm²)	Max. current (A)	Length (mm)	Length (m)	Color	Stock	Price ( ExVAT )
389 51046	2613-IEC-25BL 109718	Silicone	-60 / +180	1,5	25	250		Blue	Login required
389 51049	2613-IEC-25BC 109717	Silicone	-60 / +180	1,5	25	250		White	Login required
389 5104Y	2613-IEC-25JV 123842	Silicone	-60 / +180	1,5	25	250		Yellow/Green	Login required
389 51042	2613-IEC-25R 109721	Silicone	-60 / +180	1,5	25	250		Red	Login required
389 51044	2613-IEC-25J 109719	Silicone	-60 / +180	1,5	25	250		Yellow	Login required
389 51050	2613-IEC-50N 109728	Silicone	-60 / +180	1,5	25	500		Black	Login required
389 51051	2613-IEC-50BN 109726	Silicone	-60 / +180	1,5	25	500		Brown	Login required
389 51052	2613-IEC-50R 109729	Silicone	-60 / +180	1,5	25	500		Red	Login required
389 51054	2613-IEC-50J 109727	Silicone	-60 / +180	1,5	25	500		Yellow	Login required
389 51055	2613-IEC-50V 109730	Silicone	-60 / +180	1,5	25	500		Green	Login required
389 51056	2613-IEC-50BL 109725	Silicone	-60 / +180	1,5	25	500		Blue	Login required
389 51059	2613-IEC-50BC 109724	Silicone	-60 / +180	1,5	25	500		White	Login required
389 5105Y	2613-IEC-50JV 123843	Silicone	-60 / +180	1,5	25	500		Yellow/Green	Login required
389 51100	2613-IEC-100N 109709	Silicone	-60 / +180	1,5	25		1	Black	Login required
389 51101	2613-IEC-100BN 109708	Silicone	-60 / +180	1,5	25		1	Brown	Login required
Code number	Supplier	Material	Temperature	Section (mm²)	Max. current (A)	Length (mm)	Length (m)	Color	Stock	Price ( ExVAT )
389 51102	2613-IEC-100R 109793	Silicone	-60 / +180	1,5	25		1	Red	Login required
389 51104	2613-IEC-100J 123799	Silicone	-60 / +180	1,5	25		1	Yellow	Login required
389 51105	2613-IEC-100V 109710	Silicone	-60 / +180	1,5	25		1	Green	Login required
389 51106	2613-IEC-100BL 109707	Silicone	-60 / +180	1,5	25		1	Blue	Login required
389 51109	2613-IEC-100BC 109792	Silicone	-60 / +180	1,5	25		1	White	Login required
389 5110Y	2613-IEC-100JV 123844	Silicone	-60 / +180	1,5	25		1	Yellow/Green	Login required
389 51150	2613-IEC-150N 109712	Silicone	-60 / +180	1,5	25		1,5	Black	Login required
389 51152	2613-IEC-150R 123802	Silicone	-60 / +180	1,5	25		1,5	Red	Login required
389 51154	2613-IEC-150J 123801	Silicone	-60 / +180	1,5	25		1,5	Yellow	Login required
389 51155	2613-IEC-150V 109713	Silicone	-60 / +180	1,5	25		1,5	Green	Login required
389 51156	2613-IEC-150BL 109711	Silicone	-60 / +180	1,5	25		1,5	Blue	Login required
389 51159	2613-IEC-150BC 123800	Silicone	-60 / +180	1,5	25		1,5	White	Login required
389 5115Y	2613-IEC-150JV 123845	Silicone	-60 / +180	1,5	25		1,5	Yellow/Green	Login required
389 51200	2613-IEC-200N 109715	Silicone	-60 / +180	1,5	25		2	Black	Login required
389 51202	2613-IEC-200R 123805	Silicone	-60 / +180	1,5	25		2	Red	Login required
Code number	Supplier	Material	Temperature	Section (mm²)	Max. current (A)	Length (mm)	Length (m)	Color	Stock	Price ( ExVAT )
389 51204	2613-IEC-200J 123804	Silicone	-60 / +180	1,5	25		2	Yellow	Login required
389 51205	2613-IEC-200V 109716	Silicone	-60 / +180	1,5	25		2	Green	Login required
389 51206	2613-IEC-200BL 109714	Silicone	-60 / +180	1,5	25		2	Blue	Login required
389 51209	2613-IEC-200BC 123803	Silicone	-60 / +180	1,5	25		2	White	Login required
389 5120Y	2613-IEC-200JV 123846	Silicone	-60 / +180	1,5	25		2	Yellow/Green	Login required
389 71040	2614-IEC-25N 109749	Silicone	-60 / +180	2,5	36	250		Black	Login required
389 71042	2614-IEC-25R 109750	Silicone	-60 / +180	2,5	36	250		Red	Login required
389 71044	2614-IEC-25J 109748	Silicone	-60 / +180	2,5	36	250		Yellow	Login required
389 71045	2614-IEC-25V 109751	Silicone	-60 / +180	2,5	36	250		Green	Login required
389 71046	2614-IEC-25BL 109747	Silicone	-60 / +180	2,5	36	250		Blue	Login required
389 71049	2614-IEC-25BC 109746	Silicone	-60 / +180	2,5	36	250		White	Login required
389 7104Y	2614-IEC-25JV 123818	Silicone	-60 / +180	2,5	36	250		Yellow/Green	Login required
389 71050	2614-IEC-50N 109761	Silicone	-60 / +180	2,5	36	500		Black	Login required
389 71052	2614-IEC-50R 109762	Silicone	-60 / +180	2,5	36	500		Red	Login required
389 71054	2614-IEC-50J 109760	Silicone	-60 / +180	2,5	36	500		Yellow	Login required
Code number	Supplier	Material	Temperature	Section (mm²)	Max. current (A)	Length (mm)	Length (m)	Color	Stock	Price ( ExVAT )
389 71055	2614-IEC-50V 109763	Silicone	-60 / +180	2,5	36	500		Green	Login required
389 71056	2614-IEC-50BL 109759	Silicone	-60 / +180	2,5	36	500		Blue	Login required
389 71059	2614-IEC-50BC 109758	Silicone	-60 / +180	2,5	36	500		White	Login required
389 7105Y	2614-IEC-50JV 123819	Silicone	-60 / +180	2,5	36	500		Yellow/Green	Login required
389 71100	2614-IEC-100N 109738	Silicone	-60 / +180	2,5	36		1	Black	Login required
389 71101	2614-IEC-100BN 224454	Silicone	-60 / +180	2,5	36		1	Brown	Login required
389 71102	2614-IEC-100R 109795	Silicone	-60 / +180	2,5	36		1	Red	Login required
389 71104	2614-IEC-100J 109794	Silicone	-60 / +180	2,5	36		1	Yellow	Login required
389 71105	2614-IEC-100V 109739	Silicone	-60 / +180	2,5	36		1	Green	Login required
389 71106	2614-IEC-100BL 109737	Silicone	-60 / +180	2,5	36		1	Blue	Login required
389 71109	2614-IEC-100BC 123816	Silicone	-60 / +180	2,5	36		1	White	Login required
389 7110Y	2614-IEC-100JV 123847	Silicone	-60 / +180	2,5	36		1	Yellow/Green	Login required
389 71150	2614-IEC-150N 109741	Silicone	-60 / +180	2,5	36		1,5	Black	Login required
389 71152	2614-IEC-150R 109798	Silicone	-60 / +180	2,5	36		1,5	Red	Login required
389 71154	2614-IEC-150J 109797	Silicone	-60 / +180	2,5	36		1,5	Yellow	Login required
Code number	Supplier	Material	Temperature	Section (mm²)	Max. current (A)	Length (mm)	Length (m)	Color	Stock	Price ( ExVAT )
389 71155	2614-IEC-150V 109742	Silicone	-60 / +180	2,5	36		1,5	Green	Login required
389 71156	2614-IEC-150BL 109740	Silicone	-60 / +180	2,5	36		1,5	Blue	Login required
389 71159	2614-IEC-150BC 109796	Silicone	-60 / +180	2,5	36		1,5	White	Login required
389 7115Y	2614-IEC-150JV 123848	Silicone	-60 / +180	2,5	36		1,5	Yellow/Green	Login required
389 71200	2614-IEC-200N 109744	Silicone	-60 / +180	2,5	36		2	Black	Login required
389 71201	2614-IEC-200BN 224459	Silicone	-60 / +180	2,5	36		2	Brown	Login required
389 71202	2614-IEC-200R 109801	Silicone	-60 / +180	2,5	36		2	Red	Login required
389 71204	2614-IEC-200J 109800	Silicone	-60 / +180	2,5	36		2	Yellow	Login required
389 71205	2614-IEC-200V 109745	Silicone	-60 / +180	2,5	36		2	Green	Login required
389 71206	2614-IEC-200BL 109743	Silicone	-60 / +180	2,5	36		2	Blue	Login required
389 71209	2614-IEC-200BC 109799	Silicone	-60 / +180	2,5	36		2	White	Login required
389 7120Y	2614-IEC-200JV 123849	Silicone	-60 / +180	2,5	36		2	Yellow/Green	Login required
